Laser marking machine for nonmetal materials 80w/100w CO2 glass tube

Laser marking machine for nonmetal materials 80w/100w CO2 glass tube

Laser marking machine for nonmetal materials 80w/100w CO2 glass tube

Product Details:

Place of Origin: Linyi city,China
Brand Name: DESTINY-TECH
Certification: CE certificate 1 yeas warranty
Model Number: DT-80/100

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 0-8000USD
Packaging Details: CE standard wooden case
Delivery Time: 7 workdays
Payment Terms: T/T advance
Supply Ability: 500 sets/month
Detailed Product Description
Laser Type: Glass CO2 Laser Tube Cooling Type: Water Chiller Cooling System
Laser Power: 80W/100W Working Area: 100mm*100mm;200mm*200mm;300mm*300mm
Warranty: 1 Years For Whole Machine Optional Device: Rotary Device
Applicable Materials: Wood,glass, MDF,Paper,leather Etc. Nonmetal Materials

DESTINY-TECH ideas: To be your counselor, to be your partner, to be your friends.

DT-CO2 glass tube Laser marking machine for nonmetal materials 80w/100w

Machine parameters

Model

DT-80

DT-100

Rated Laser Output Power

80W

100W

Marking area

110*110mm

200*200mm

300*300mm

Laser wavelength

10.64μm

Marking depth

0.01-0.03mm(depend on the material)

Scan Speed

0-7000mm/s

Scanning system

Laser Vibration lens

Pulse Frequency

20KHz

Power required

110v/60Hz or 220v/50Hz

Cooling Mode

Water cooling

Machine features

Glass tube CO2 laser marking machine adopts CO2 glass laser tube and generator and vibration lens.It is integrative design, beautiful structure,high output power,good energy stability, simple and convenient operation, reliable performance, wide application and other characteristics.

Applied the national AUTCAD,CORELDRAW,PHOTOSHOP software input target design easily.Can mark bar code, two-dimension code,graph and words,support PLI,PCX,DXF,BMP.

Computer-control,English system,easy operation.

Machine applicable materials

CO2 laser marking machines engraving a variety of non-metallic materials, widely used in leather, wood, textile, plastics, plates and packaging, crafts, electronics, telecommunications, watches, glasses, printing, decoration and other industries.

Engraving materials mainly include bamboo and wood products, paper and cloth, leather, plexiglass, epoxy resin, acrylic, polyester, and other non-metallic materials

After-sale service and Warranty

1.  Two years guarantee for the whole laser machine. All the machines are produced according to standard to keep the quality.

2.  If the machine is with any problem, our technician will help to solve online first time by Skype, email ,Whatsapp, Wechat etc. or by phone if urgently . We have excellent engineers speaking English,          they are available at 24 hours .No time difference limitation . Can supply the solution for any problems. In addition ,they also can go to your country to solve the machine problems if you can't solve        yourself online .

3. There are detail machine operation manual and video CD sent together with the machine.

If you like it , please send us inquiry or contact with us for more detail information .We will offer our best solution for you .DESTINY-TECH welcome you .
