Textile laser cutting DT-1830 safa fabric auto-feed fabric CO2 laser cutting machine

Textile laser cutting DT-1830 safa fabric auto-feed fabric CO2 laser cutting machine

    • Textile laser cutting DT-1830 safa fabric auto-feed fabric CO2 laser cutting machine
    • Textile laser cutting DT-1830 safa fabric auto-feed fabric CO2 laser cutting machine
    • Textile laser cutting DT-1830 safa fabric auto-feed fabric CO2 laser cutting machine
  • Textile laser cutting DT-1830 safa fabric auto-feed fabric CO2 laser cutting machine

    Product Details:

    Place of Origin: Linyi city,China
    Brand Name: DESTINY-TECH
    Certification: CE certificate 2 yeas warranty
    Model Number: DT-1830

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 0-20000 USD
    Packaging Details: CE standard wooden case
    Delivery Time: 20 workdays
    Payment Terms: T/T advance
    Supply Ability: 500 sets/month
    Contact Now
    Detailed Product Description
    Laser Type: Sealed CO2 Laser Tube Cooling Type: Water Chiller Cooling System
    Laser Power: 80W ,100W , 150W Working Area: 1800mm*3000m
    Blower: Air Compressor

    ESTINY-TECH ideas: To be your counselor, to be your partner, to be your friends.

    DT-1630 safa fabric special auto-feed fabric CO2 laser cutting machine

    Machine parameters

    Machine Model

    DT-1830  Safa fabric auto feeding

    Working Size

    1800 * 3000 mm / 70.8 in * 118 in ( X * Y axis)

    Laser Power

    100w/150w

    Laser Type

    Sealed CO2 glass laser tube, water-cooling ,10.6nm

    Driving System

    3-Phase Stepper Motor &Belts transmission

    Cutting Speed

    0-40000mm/min  (1575inch/min)

    Engraving Speed

    0-60000mm/min  (2362 inch/min)

    Laser Output Control

    1-100% software setting

    Resetting Position Accuracy

    ≤±0.01

    Smallest  Character

    Chinese 2.0 *2.0mm English 1.0*1.0mm

    Highest Scanning precision

    2500 DPI

    Power Supply

    220V/50Hz,  110V/60Hz,

    Operating Temperature

    0-45℃

    Operating Humidity

    5-95%

    Operating System

    DSP CNC Control System in Win XP, Win 7

    Graphic Format Supported

    BMP, PLT, AI, DST, DXF

    Software Supported

    Corel draw, Photoshop, AutoCAD, Tajima

    Optional device

    Red light  pointer

    Color separation

    Yes





















































    Product descriptions

    Laser cutting is now the people of various cutting techniques to master the best cutting method, compared with small heat the traditional cutting, laser cutting has the advantage of:  distortion, high cutting precision, low noise, no pollution, easy to implement automatic cutting Although the initial investment large (weaknesses), but the processing cost than mechanical processing to 50% less.

    Laser cutting is an advanced manufacturing technology, with a wide range of applications, process flexibility, high precision, good quality, clean, and easy to implement production process automation, flexible, intelligent, and improve product quality, labor productivity and so on.

    Our company specializes in sofa fabric cutting industry developed a fully automatic cutting process, instead of the original cut and the cutting process catcher two kinds of steps to achieve a full intelligent cutting.

    Traditional sofa manufacturing process: According to the professional division of labor, improving the efficiency of the principles of the sofa process is divided into five section: Framework section, the main production sofa frame; exterior section, the main production sofa exposed components; lined section, the preparation of all kinds sponge inner core; jacket section, cutting sewing jackets; assembly (palpable skin) section, each section of each front semi-coupled materials, assembled into a complete sofa.

    Now according to the traditional sofa process improvement, the jacket section was omitted, the template after the original production, according to the template cutting, lock cropped edges; all with our current automatic cutting bed instead.

    Machine advantages

    The sample model can be made picture one time, save forever with 1:1 precision size. Automatic material arrangement software can save the time and labour and also save every millimeter cloth for you.

    software special for sofa industry, easy operation, intelligent segmentation, intelligent interrupt; very suitable for long layout successive cutting

    totally automatic-feeding system; perfect combination of laser software, camera and typesetting system; high cutting speed; high cutting precision; auto sewing of fabric. This machine is equipped with three blowers, very good exhaust. It is equipped with movable collecting device, very easy to collect cutting pieces.

    Applicable Materials
    Safa cloth, fabric, leather, woolen, paper, film etc. soft materials

    Applicable Industries
    Safa making industry, Garment,car inside decoration materials ,leather,toys indsutry, computerized embroidery and clipping, cutting of template, art gift, advertisement decoration,building upholster, package, printing, paper product and other industries.

    After-sale service and Warranty

    1.  Two years guarantee for the whole laser machine. All the machines are produced according to standard to keep the quality.

    2.  If the machine is with any problem, our technician will help to solve online first time by Skype, email ,Whatsapp, Wechat etc. or by phone if urgently . We have excellent engineers speaking English,they are available at 24 hours .No time difference limitation . Can supply the solution for any problems. In addition ,they also can go to your country to solve the machine problems if you can't solve yourself online .

    3. There are detail machine operation manual and video CD sent together with the machine.



    If you like it , please send us inquiry or contact with us for more detail information .We will offer our best solution for you .DESTINY-TECH welcome you .
