Metal cutting DT-1325/1530 300W Fiber laser cutting machine for Stainless & Carbon steel

Metal cutting DT-1325/1530 300W Fiber laser cutting machine for Stainless & Carbon steel

Metal cutting DT-1325/1530 300W Fiber laser cutting machine for Stainless & Carbon steel

Product Details:

Place of Origin: Linyi city,China
Brand Name: DESTINY-TECH
Certification: CE certificate 2 yeas warranty
Model Number: DT-1325/1530

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 0-50000USD
Packaging Details: CE standard wooden case
Delivery Time: 30 workdays
Payment Terms: T/T advance
Supply Ability: 200 sets/month
Detailed Product Description
Laser Type: Fiber Laser Device Cooling Type: Air Cooling And Water Chiller Cooling System
Laser Power: Raycus Or IPG Brand 500W Fiber Laser Working Area: 1300mm*2500m Or 1500mm*3000mm
Gas Type: Oxygen Or Hydrogen Tranmission System: Rack Pinion And Square Guide Rail
Motor And Drivers: Japan Panasonic Servo Motor And Drivers Warranty: 1 Years For Whole Machine
Fiber Laser Power: 300W RAYCUS Fiber Laser Device

DESTINY-TECH ideas: To be your counselor, to be your partner, to be your friends.

DT-1325/1530 Fiber 300W steel laser cutting machine with racks transmission system

Machine parameters

Machine Model

DT-1325/ 1530

Working area

1300*2500mm / 1500*3000mm

Laser power

300W Raycus brand fiber laser device

laser head

Friendness laser head , with auto sensor,

adjust focal distance automatically

Cutting thickness

0.2-2mm stainless steel / 0.2-4mm carbon steel

Cooling system

CW-6100 water chiller

Rated power

10-100%

Laser wavelength

1060nm

X,Y-axis location accuracy

±0.01mm

X,Y-axis repeat location accuracy

±0.01mm

X,Y-axis fast moving speed

25m/min

X,Y-axis max cutting speed

20m/min

Min. cutting line width

0.01

Machine size

4.0×2.5×1.5m

After-sale service

Technician available for training and installation











































































Machine configurations

Term

Model

Parts

Amount

Brand

1

DY FIBER 500W

Machine bed

1 set

DESTINY-TECH

2

Fiber laser device

1 set

China Raycus

3

Laser head

1 set

Friendness laser head

4

Water chiller

1 set

CW 6100

5

Servo motor

3 sets

Panasonic

6

Control system

1 set

Bochu (Cypcut) system

7

Racks

2 sets

Imported

8

Working area

1300 * 2500mm

1500 * 3000mm

Working area optional



Machine Features

DT -1325/ 1530 300W Fiber laser cutting machine is designed for the customers who want to cut steel below 4mm thickness by laser cutter.

With stable and practical advantages, this machine have a high price performance. We designed to satisfy the

customer who want lower investment while higher stability laser machines. We chose to use RAYCUS brand high stability laser generator, gantry bed structure which ensure the machine stability,fast cutting and long life span.The machine can cut 0-2mm stainless steel(Max. 3mm) and 0-4mm carbon steel. You can choose the working size according your steel sheet size . It's with high-performance transmission system Japanese Panasonic servo motor & Rack and gear,The motion system is excellent , that suit for the fast working. We adopts Friendness brand auto follow-up cutting head system with high sensitivity and stability. The cutting head moving with the variation of the plate.The cut-off point position will remain unchanged. The kerf is flat and smooth enough no need to handle it again.Meanwhile, the machine can be use to cut both of the flat materials and curving materials. This machine is with high performance-price ratio, Low cost for using, Low fees for the future maintain .With drawer to collect the garbage, easy to change the gas valve. Compare with same fiber industry , it's really a good choice with lower price to do same job .

Applicable materials and industries

This fiber laser can cut stainless steel, mild steel,titanium plate, iron, etc  It's widely used in aerospace technology, rocket, plane, robot, elevator, steamship and automobile manufacturing and metalparts processing industry for metal plate, advertisement, kitchen ware, bit tool, hardware etc.

After-sale service and Warranty

1.  Two years guarantee for the whole laser machine. All the machines are produced according to standard to keep the quality.

2.  If the machine is with any problem, our technician will help to solve online first time by Skype, email ,Whatsapp, Wechat etc. or by phone if urgently . We have excellent engineers speaking English,  they are available at 24 hours .No time difference limitation . Can supply the solution for any problems. In addition ,for this kind laser cutting machine ,it's neccessay to send technician to go to your country to install and train if you demand .

3. There are detail machine operation manual and video CD sent together with the machine.



If you like it , please send us inquiry or contact with us for more detail information .We will offer our best solution for you .DESTINY-TECH welcome you .
