Place of Origin: | Linyi city,China |
Brand Name: | DESTINY-TECH |
Certification: | CE certificate 1 yeas warranty |
Model Number: | DT-80/100 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | 0-8000USD |
Packaging Details: | CE standard wooden case |
Delivery Time: | 7 workdays |
Payment Terms: | T/T advance |
Supply Ability: | 500 sets/month |
Laser Type: | Glass CO2 Laser Tube | Cooling Type: | Water Chiller Cooling System |
---|---|---|---|
Laser Power: | 80W/100W | Working Area: | 100mm*100mm;200mm*200mm;300mm*300mm |
Warranty: | 1 Years For Whole Machine | Optional Device: | Rotary Device |
Applicable Materials: | Wood,glass, MDF,Paper,leather Etc. Nonmetal Materials |
DESTINY-TECH ideas: To be your counselor, to be your partner, to be your friends.
DT-CO2 glass tube Laser marking machine for nonmetal materials 80w/100w
Machine parameters
Model |
DT-80 |
DT-100 |
||
Rated Laser Output Power |
80W |
100W |
||
Marking area |
110*110mm |
200*200mm |
300*300mm |
|
Laser wavelength |
10.64μm |
|||
Marking depth |
0.01-0.03mm(depend on the material) |
|||
Scan Speed |
0-7000mm/s |
|||
Scanning system |
Laser Vibration lens |
|||
Pulse Frequency |
20KHz |
|||
Power required |
110v/60Hz or 220v/50Hz |
|||
Cooling Mode |
Water cooling |
Machine features
Glass tube CO2 laser marking machine adopts CO2 glass laser tube and generator and vibration lens.It is integrative design, beautiful structure,high output power,good energy stability, simple and convenient operation, reliable performance, wide application and other characteristics.
Applied the national AUTCAD,CORELDRAW,PHOTOSHOP software input target design easily.Can mark bar code, two-dimension code,graph and words,support PLI,PCX,DXF,BMP.
Computer-control,English system,easy operation.
Machine applicable materials
CO2 laser marking machines engraving a variety of non-metallic materials, widely used in leather, wood, textile, plastics, plates and packaging, crafts, electronics, telecommunications, watches, glasses, printing, decoration and other industries.
Engraving materials mainly include bamboo and wood products, paper and cloth, leather, plexiglass, epoxy resin, acrylic, polyester, and other non-metallic materials
After-sale service and Warranty
1. Two years guarantee for the whole laser machine. All the machines are produced according to standard to keep the quality.
2. If the machine is with any problem, our technician will help to solve online first time by Skype, email ,Whatsapp, Wechat etc. or by phone if urgently . We have excellent engineers speaking English, they are available at 24 hours .No time difference limitation . Can supply the solution for any problems. In addition ,they also can go to your country to solve the machine problems if you can't solve yourself online .
3. There are detail machine operation manual and video CD sent together with the machine.
If you like it , please send us inquiry or contact with us for more detail information .We will offer our best solution for you .DESTINY-TECH welcome you .
